Анализатор прочности термосвариваемой пленки БОПП GBB-A1

Тестер термосваривания предназначен для проверки температуры, давления и времени термосваривания различных пленочных материалов.

GBB-A 热封分析仪 用于测试各种薄膜材料热封的温度、压力和时间。

广泛应用于塑料薄膜、食品、医药、检验机构、研究所等行业。

Product Introduction

GBB-C vertical heat seal tester can accurately measure the heat sealing temperature, heat sealing time, heat sealing pressure, and other heat sealing performance parameters of plastic packaging vertical bags, paper-plastic composite vertical bags and metal composite vertical bags(boxes). The heat sealing performance of samples of different materials are different. And the best heat sealing conditions can be accurately obtained through the determination of their heat sealing performance parameters.

Testing Principle

Put the sample on the lower tray of the instrument, adjust the appropriate height according to the size of the sample, set a certain sealing temperature, time and pressure as required, and start the instrument with one key. The fixture on the instrument will heat seal the sample according to the setting parameters. Under the manual state, step on the foot switch, and the heat sealing knife is pressed. The heat sealing time is determined by the value set by the time control. In the automatic state, the upper and lower heat sealing knives of the heat sealer will automatically heat seal repeatedly according to the set time.

Standards

ASTM F 2029

Specifications

Characteristics

u High progress imported quality sensor, quality assurance

Original imported temperature sensor, wide temperature control range, high sensitivity, temperature control accuracy of ± 1 ℃, it has ultra-high stability and ultra-low failure rate.

u Independent control of heat sealing temperature

The rear of the heat sealing knife is equipped with a temperature sensor, and the temperature control of the inner and outer sealing knives is independent and set separately.

u Personalized test selection

Manual testing and automatic testing are free to choose. The automatic mode is time-saving and convenient, and the repeatability is fully automatic for heat-sealing the sample; the manual mode is equipped with a suitable foot switch, step on the foot switch, the heat sealing knife is pressed, and the safety protection is easy to operate.

u New air drive system

The drive system consists of a pressure gauge, a pressure regulating valve, and a cylinder. After the compressed air is introduced, the pressure is adjusted through the pressure valve, the air pressure can be accurately locked, and the heat sealing clamp is pneumatically driven, which is convenient and efficient.

u Wider range of customized services

The anti-sticking function of the heat sealing knife can be upgraded as needed, experience upgrade, and it is more intuitive and convenient to determine the best heat sealing conditions.

The shape, size and smoothness of the sealing knife heat cover can be customized to meet different scientific research needs.

Application

Application

GBB-F1 Heat Seal Tester is to test the temperature, pressure, and time for heat sealing of various film materials. It is applied to quality inspection organizations, drug control institutions, research institutes, packaging, thin film, food companies, pharmaceutical enterprises, personal care industry and so on.

Standards

QB/T 2358, ASTM F 2029, YBB00122003

Features

      Five point heat seal, can set six different temperature at the same time (low bar and five upper bars).

      Upper and lower heat seal bars have independent temperature control and setting.

      The equipment adopts digital P.I.D. temperature to control, the temperature is more accurate. Temperature sensor is easy to calibrate.

       Using compressed air, pneumatic drive. pressure test, convenient to set pressure according to sample from customer.

Specifications
